BỘ KẸP CHÂN KHÔNG VMECA SERIES G80

Mã sản phẩm : VMECA - G80

Xuất xứ : VMECA - KOREA

Bảo hành : Theo tiêu chuẩn nhà sản xuất

V-Grip: Bọt Pad Mức chân không tối đa: -85 kPa Tốc độ dòng chảy tối đa: 724 Nl / phút Tiêu thụ không khí: 208 Nl / phút Chiều rộng: 84 mm

Giá sản phẩm : 0985.288.164

HOTLINE TƯ VẤN : 0985.288.164

► SƠ ĐỒ CHỌN MÃ KẸP CHÂN KHÔNG VMECA SERIES G80:

1. Basic Model

Symbol	Description
G80X150-MC2	Vacuum gripper, V-grip G series, 2-mini cartridge, Foam pad, 80x150mm
G80X200-MC2	Vacuum gripper, V-grip G series, 2-mini cartridge, Foam pad, 80x200mm
G80X220-LC2	Vacuum gripper, V-grip G series, 2-midi cartridge, Foam pad, 80x220mm
G80X250-LC2	Vacuum gripper, V-grip G series, 2-midi cartridge, Foam pad, 80x250mm
G80X300-L2	Vacuum gripper, V-grip G series, 2-midi cartridge, Foam pad, 80x300mm

2. Vacuum Port

Symbol	Description
ES1	Standard, Fixed 1mm Nozzle Size, Narrow Spacing
ES2	Standard, Fixed 2mm Nozzle Size, Narrow Spacing
AW	Adjustable Nozzle Size, Wide Spacing

3. Air Control Valve

4. Vacuum Release Control Valve

Symbol	Description
Blank	No vacuum release control valve
R1	Vacuum release control valve, AC 110V
R2	Vacuum release control valve, AC 220V
R3	Vacuum release control valve, DC 24V

5. Valve Terminal

Symbol	Description
Blank	No air & vacuum release control valves
DN	Solenoid terminal, DIN type, No lead wire
DL	Solenoid terminal, DIN type, No lead wire, Lamp
CL	Solenoid terminal, Connector type, 30 cm lead wire
	☛ Option “CL” is available only with DC 24V.

6. Vacuum Switch

Symbol	Description
Blank	No vacuum switch
S2	Digital switch, No analog supply, M8-4-pin, NPN
S2P	Digital switch, No analog supply, M8-4-pin, PNP
SG2	Digital switch, No analog supply, 2 m lead wire, NPN
SG2P	Digital switch, No analog supply, 2 m lead wire, PNP
SG3	Digital switch, Analog supply, 2 m lead wire, NPN
SG3P	Digital switch, Analog supply, 2 m lead wire, PNP

► Phụ tùng:

1. Air Control Valve

Part Number	Description
VMS14-3-1	2/2-way sol valve, G1/4″ Inlet, DC 24V, DIN type
VMS14-3-2	2/2-way sol valve, G1/4″ Inlet, DC 24V, DIN type, Lamp
VMS14-3-3	2/2-way sol valve, G1/4″ Inlet, DC 24V, Conn. type, 30 cm lead wire & Lamp
VMS14-2-1	2/2-way sol valve, G1/4″ Inlet, AC 220V, DIN type
VMS14-2-2	2/2-way sol valve, G1/4″ Inlet, AC 220V, DIN type, Lamp
VMS14-1-1	2/2-way sol valve, G1/4″ Inlet, AC 110V, DIN type
VMS14-1-2	2/2-way sol valve, G1/4″ Inlet, AC 110V, DIN type, Lamp
MS18-3-1	2/2-way sol valve, G1/8″ Inlet, DC 24V, DIN type
MS18-3-2	2/2-way sol valve, G1/8″ Inlet, DC 24V, DIN type, Lamp
MS18-3-3	2/2-way sol valve, G1/8″ Inlet, DC 24V, Conn. type, 30 cm lead wire & Lamp
MS18-2-1	2/2-way sol valve, G1/8″ Inlet, AC 220V, DIN type
MS18-2-2	2/2-way sol valve, G1/8″ Inlet, AC 220V, DIN type, Lamp
MS18-1-1	2/2-way sol valve, G1/8″ Inlet, AC 110V, DIN type

2. Vacuum Switch & Gauge

Part Number	Description
VTG-18+N	Vacuum Gauge, Dial Type, Mounting Nut
VP20V-01-F1-C	Digital switch, No analog supply, M8-4-pin connector, NPN (S2)
VP20V-03-F1-C	Digital switch, No analog supply, M8-4-pin connector, PNP (S2P)
VP20V-01-F1	Digital switch, No analog supply, 2 m lead wire, NPN (SG2)
VP20V-03-F1	Digital switch, No analog supply, 2 m lead wire, PNP (SG2P)
VP20V-01-F1-A	Digital switch, Analog supply, 2 m lead wire, NPN (SG3)
VP20V-03-F1-A	Digital switch, Analog supply, 2 m lead wire, PNP (SG3P)
