BỘ KẸP CHÂN KHÔNG VMECA SERIES G200
VMECA - G200
VMECA - KOREA
Theo tiêu chuẩn nhà sản xuất
V-Grip: Bọt Pad
Mức chân không tối đa: -75 kPa
Tốc độ dòng chảy tối đa: 2.896 Nl / phút
Tiêu thụ không khí: 832 Nl / phút
Chiều rộng: 204 mm
0985.288.164
HOTLINE TƯ VẤN : 0985.288.164
► SƠ ĐỒ CHỌN MÃ KẸP CHÂN KHÔNG VMECA SERIES G200:
1. Basic Model
| Symbol | Description |
| G200X300-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x300mm |
| G200X400-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x400mm |
| G200X600-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x600mm |
| G200X600-L6 | Vacuum gripper, V-grip G series, 6-midi cartridge, Foam pad, 200x600mm |
| G200X600-L8 | Vacuum gripper, V-grip G series, 8-midi cartridge, Foam pad, 200x600mm |
| G200X800-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x800mm |
| G200X800-L6 | Vacuum gripper, V-grip G series, 6-midi cartridge, Foam pad, 200x800mm |
| G200X800-L8 | Vacuum gripper, V-grip G series, 8-midi cartridge, Foam pad, 200x800mm |
| G200X1000-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x1000mm |
| G200X1000-L6 | Vacuum gripper, V-grip G series, 6-midi cartridge, Foam pad, 200x1000mm |
| G200X1000-L8 | Vacuum gripper, V-grip G series, 8-midi cartridge, Foam pad, 200x1000mm |
| G200X1200-L4 | Vacuum gripper, V-grip G series, 4-midi cartridge, Foam pad, 200x1200mm |
| G200X1200-L6 | Vacuum gripper, V-grip G series, 6-midi cartridge, Foam pad, 200x1200mm |
| G200X1200-L8 | Vacuum gripper, V-grip G series, 8-midi cartridge, Foam pad, 200x1200mm |
2. Vacuum Port
| Symbol | Description |
| ES1 | Standard, Fixed 1mm Nozzle Size, Narrow Spacing |
| ES2 | Standard, Fixed 2mm Nozzle Size, Narrow Spacing |
| AW | Adjustable Nozzle Size, Wide Spacing |
3. Air Control Valve
| Symbol | Description |
| Blank | No air control valve |
| A1 | Air control valve, AC 110V |
| A2 | Air control valve, AC 220V |
| A3 | Air control valve, DC 24V |
4. Vacuum Release Control Valve
| Symbol | Description |
| Blank | No vacuum release control valve |
| R1 | Vacuum release control valve, AC 110V |
| R2 | Vacuum release control valve, AC 220V |
| R3 | Vacuum release control valve, DC 24V |
5. Valve Terminal
| Symbol | Description |
| Blank | No air & vacuum release control valves |
| DN | Solenoid terminal, DIN type, No lead wire |
| DL | Solenoid terminal, DIN type, No lead wire, Lamp |
| CL | Solenoid terminal, Connector type, 30 cm lead wire |
| ☛ Option “CL” is available only with DC 24V. |
6. Vacuum Switch
| Symbol | Description |
| Blank | No vacuum switch |
| S2 | Digital switch, No analog supply, M8-4-pin, NPN |
| S2P | Digital switch, No analog supply, M8-4-pin, PNP |
| SG2 | Digital switch, No analog supply, 2 m lead wire, NPN |
| SG2P | Digital switch, No analog supply, 2 m lead wire, PNP |
| SG3 | Digital switch, Analog supply, 2 m lead wire, NPN |
| SG3P | Digital switch, Analog supply, 2 m lead wire, PNP |
► Phụ tùng:
1. Air Control Valve
| Part Number | Description |
| VMS14-3-1 | 2/2-way sol valve, G1/4″ Inlet, DC 24V, DIN type |
| VMS14-3-2 | 2/2-way sol valve, G1/4″ Inlet, DC 24V, DIN type, Lamp |
| VMS14-3-3 | 2/2-way sol valve, G1/4″ Inlet, DC 24V, Conn. type, 30 cm lead wire & Lamp |
| VMS14-2-1 | 2/2-way sol valve, G1/4″ Inlet, AC 220V, DIN type |
| VMS14-2-2 | 2/2-way sol valve, G1/4″ Inlet, AC 220V, DIN type, Lamp |
| VMS14-1-1 | 2/2-way sol valve, G1/4″ Inlet, AC 110V, DIN type |
| VMS14-1-2 | 2/2-way sol valve, G1/4″ Inlet, AC 110V, DIN type, Lamp |
| MS18-3-1 | 2/2-way sol valve, G1/8″ Inlet, DC 24V, DIN type |
| MS18-3-2 | 2/2-way sol valve, G1/8″ Inlet, DC 24V, DIN type, Lamp |
| MS18-3-3 | 2/2-way sol valve, G1/8″ Inlet, DC 24V, Conn. type, 30 cm lead wire & Lamp |
| MS18-2-1 | 2/2-way sol valve, G1/8″ Inlet, AC 220V, DIN type |
| MS18-2-2 | 2/2-way sol valve, G1/8″ Inlet, AC 220V, DIN type, Lamp |
| MS18-1-1 | 2/2-way sol valve, G1/8″ Inlet, AC 110V, DIN type |
2. Vacuum Switch & Gauge
| Part Number | Description |
| VTG-18+N | Vacuum Gauge, Dial Type, Mounting Nut |
| VP20V-01-F1-C | Digital switch, No analog supply, M8-4-pin connector, NPN (S2) |
| VP20V-03-F1-C | Digital switch, No analog supply, M8-4-pin connector, PNP (S2P) |
| VP20V-01-F1 | Digital switch, No analog supply, 2 m lead wire, NPN (SG2) |
| VP20V-03-F1 | Digital switch, No analog supply, 2 m lead wire, PNP (SG2P) |
| VP20V-01-F1-A | Digital switch, Analog supply, 2 m lead wire, NPN (SG3) |
| VP20V-03-F1-A | Digital switch, Analog supply, 2 m lead wire, PNP (SG3P) |
3. Vacuum Cartridge
| Part Number | Description |
| VC303 | Midi vacuum cartridge, 3-stage |
4. Other Parts
| Part Number | Description |
| Sponge Foam | Call |
Công ty rất hân hạnh được phục vụ nhu cầu của quý khách, vui lòng liên hệ tại đây:
CÔNG TY TNHH KỸ THUẬT VÀ DỊCH VỤ MINH PHÚ
Địa chỉ: Số 244/44, Đường Dương Đình Hội, Phường Tăng Nhơn Phú B, Quận 9, Thành phố Hồ Chí Minh, Việt Nam
Hotline, zalo, skype: 0985.288.164 ( Mr.Hải )
Email: hoanghai@minhphuco.vn
Website: www.thietbinanghachankhong.vn
