1. Basic Model
Symbol |
Description |
VTX5 |
Minimultiple, VTX5 |
2. Number of Stacks
Symbol |
Description |
2 |
Minimultiple, VTX5, 2-stacked pump |
4 |
Minimultiple, VTX5, 4-stacked pump |
6 |
Minimultiple, VTX5, 6-stacked pump |
8 |
Minimultiple, VTX5, 8-stacked pump |
10 |
Minimultiple, VTX5, 10-stacked pump |
12 |
Minimultiple, VTX5, 12-stacked pump |
14 |
Minimultiple, VTX5, 14-stacked pump |
16 |
Minimultiple, VTX5, 16-stacked pump |
3. Air Control Valve
Symbol |
Description |
Blank |
No air control valve |
A1 |
Air control valve, AC 110V |
A2 |
Air control valve, AC 220V |
A3 |
Air control valve, DC 24V |
4. Valve Terminal
Symbol |
Description |
Blank |
No air control valve ☛ “Option 2”, Air control valve |
DN |
Solenoid terminal, DIN type, No lead wire |
DL |
Solenoid terminal, DIN type, No lead wire, Lamp |
CL |
Solenoid terminal, Connector type, 30 cm lead wire |
|
☛ “The valve terminal ” option is only available when you chose air control valve. |
|
☛ “CL” option is only available with DC24V. |
2B |
Solenoid terminal, DIN, 2-in-1 BUS cable |
5. Vacuum Port
Symbol |
Description |
2 |
Push-in fitting, 2 mm inner diameter |
4 |
Push-in fitting, 4 mm inner diameter |
6. Sealing Material
Symbol |
Description |
Blank |
NBR sealing material |
V |
Viton sealing material |
E |
EPDM sealing material |
Max Vacuum Level |
-92 kPa |
Open Vacuum Flow |
24 Nl/min |
Feed Pressure |
5.5 bar (Max 7 bar) |
Air Consumption |
24 Nl/min |
Temperature |
-20 ~ 80 ℃ |
Weight: VTX5X2: |
67 g (Increased 13 g per additional stack) |
Weight: VTX5X4: |
245 g (Increased 18 g per additional stack) |
Pump |
L1 |
L2 |
2-Stack |
28 |
94 |
3-Stack |
35 |
101 |
|
No |
Description |
1 |
Compressed-Air Port, G 1/8″ |
2 |
Vacuum Port, ∅2 or ∅4mm |
3 |
Exhaust Port |
4 |
Air Control Valve |
|
Pump |
L1 |
L2 |
4-Stack |
38.3 |
48.3 |
5-Stack |
45.5 |
55.5 |
6-Stack |
53 |
63 |
7-Stack |
60 |
70 |
|
No |
Description |
1 |
Compressed-Air Port, G 1/8″ |
2 |
Vacuum Port, ∅2 or ∅4mm |
3 |
Exhaust Port |
4 |
Air Control Valve |
|
Pump |
L1 |
L2 |
8-Stack |
67.5 |
77.5 |
9-Stack |
74.8 |
84.8 |
10-Stack |
82 |
92 |
11-Stack |
88.5 |
98.5 |
12-Stack |
96 |
106 |
13-Stack |
103.2 |
113.2 |
14-Stack |
111 |
121 |
15-Stack |
118 |
128 |
16-Stack |
125.2 |
135.2 |
|
No |
Description |
1 |
Compressed-Air Port, G 1/8″ |
2 |
Vacuum Port, ∅2 or ∅4mm |
3 |
Exhaust Port |
4 |
Air Control Valve |
|
Vacuum Pumps & Spare Parts
Part Number |
Description |
MS18-3-1 |
2/2-way sol valve, G1/8″ inlet, DC 24V, DIN type |
MS18-3-2 |
2/2-way sol valve, G1/8″ inlet, DC 24V, DIN type, Lamp |
MS18-3-3 |
2/2-way sol valve, G1/8″ inlet, DC 24V, Conn. type, 30 cm lead wire & Lamp |
MS18-2-1 |
2/2-way sol valve, G1/8″ inlet, AC 220V, DIN type |
MS18-2-2 |
2/2-way sol valve, G1/8″ inlet, AC 220V, DIN type, Lamp |
MS18-1-1 |
2/2-way sol valve, G1/8″ inlet, AC 110V, DIN type |
MS18-1-2 |
2/2-way sol valve, G1/8″ inlet, AC 110V, DIN type, Lamp |
Seal Kit |
Please contact VMECA. |
