• Fluid: air • Operating pressure range: 0.1 to 1.0MPa • Effective area range mm 2 (Cv): 1(P) to 2(A) 21 - 93 (1.18 - 5.22); 2A to 3(R) 35 - 105 (1.97 - 5.90) • Ambient & fluid temperature: -5 to 60° C • Required switching force: 7.5kgf (at 1.0MPa)

• Manually operated valve that can be used to prevent accidents caused by residual pressure in pneumatic lines Possible to verify the supply and exhaust status of air flow at a glance • When in the exhaust position, the valve can be padlock secured. • This prevents accidental start-ups while personnel are cleaning or servicing equipment. • Stainless steel body with aluminum or stainless steel handle • Validated according to ISO13849

• 3 port pressure relief valve • Accessory for AC series • Lockable for energy isolation • Double action operation, push down and turn • Resin or metal handle construction • Port sizes: 1/8, 1/4, 3/8, 1/2, 3/4, 1" • Thread Types: Rc, NPT, G

• 3 port pressure relief valve • Accessory for AC series • Lockable for energy isolation • Single action operation, simply turn • Resin or metal handle construction • Port sizes: 1/8, 1/4, 3/8, 1/2, 3/4, 1" • Thread Types: Rc, NPT, G

Series VH rotary hand valve's compact design and variety of flow rates make it ideal for a wide range of applications requiring manual directional control. The slide ring design makes the VH valve easy to operate while offering a high tolerance to contamination with its "self-cleaning, wiping action".

• Valve: 2 or 3 port (flame resistant) • Fluid: air • Max. operating pressure: 1.0MPa • Effective area: 2.0 to 17.5mm² • Ambient and fluid temperature: 0 to 60°C

• Finger valve, standard • 2 or 3 port available • Effective area: 2.0 to 17.5mm² • Max. operating pressure: 1.0MPa • Fluid: air

• Indicates presence of pneumatic pressure • Port size: Rc(PT) 1/8 • Operating pressure: 0.1 to 0.8MPa • Color of indication: red, green, orange

• Miniature pneumatic indicator • Port size: R(PT) 1/8 • Operating pressure: 0.15 to 1.0MPa • Ultra compact

• Converts pneumatic signal to electric relay • Port size: Rc(PT) 1/8 • Operating pressure: 0.1 to 1.0MPa • Construction: standard, closed terminal

• Transmitter-relay valve, metric threads • Fluid: air • Operating pressure: 0 to 1.0MPa • Effective area (Cv): 7mm² (0.38) • Port size: Rc (PT) 1/8

• Supply pressure: 0 to 1.0 MPa • Signal pressure: 0.25 to 0.8MPa • Time delay: 0.5 to 60s • Operating and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.14

• 3 port check valve • Max. operating pressure: 1.0MPa • Ambient and fluid temp: -5° to 60°C • Effective area (Cv): 0.38 to 0.81

• AND valve with one-touch fitting • Maximum operating pressure: 1MPa (145 psi) • Minimum operating pressure: 0.05MPa (7 psi) • Proof pressure: 1.5MPa (218 psi) • Ambient and fluid temp: -5° to 60°C (23° to 140°F) (with no freezing)

• Shuttle valve with one-touch fitting • Maximum operating pressure: 1MPa (145 psi) • Minimum operating pressure: 0.05MPa (7 psi) • Proof pressure: 1.5MPa (218 psi) • Ambient and fluid temp: -5° to 60°C (23° to 140°F) (with no freezing)

• Operating pressure: 0.25 to 1 MPa • Proof pressure: 1.5 MPa • Ambient and fluid temperature: -5 to 60° C (No freezing) • Port size: Metric ø6, Inch ø1/4 • Optional bracket is available

• 5 port mechanical valve with foot pedal type actuation • Available with lock and without lock • Operating pressure: 0.15 to 0.9 MPa

• Fluid: air, inert gas • Operating pressure range: 0.15 to 0.9MPa • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): 300 c.p.m. or less • Weight (Basic): 260g

• Fluid: air, inert gas • Operating pressure range: 22 to 131 PSIG • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): 300 c.p.m. or less • Weight (Basic): 9.2 oz.

• Fluid: air, inert gas • Operating pressure range: 0.15 to 0.9MPa • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): 300 c.p.m. or less • Weight (Basic): 260g

• Fluid: air, inert gas • Operating pressure range: 0.1 to 1.0MPa • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): 300 c.p.m. or less • Weight: 300g

• Fluid: air, inert gas • Operating pressure range: 15 to 150 PSIG • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): • 300 c.p.m. or less • Weight: 10.3 oz.

• Fluid: air, inert gas • Operating pressure range: 0.1 to 1.0MPa • Effective area (Cv): 18mm 2 (1.0) • Maximum frequency (mechanical operation style): 300 c.p.m. or less • Weight: 300g

• Fluid: air, inert gas • Operating pressure: 0.15 to 0.7MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.6 • Thread: G(PF) • Port size: main valve 1/8, pilot valve (EXH) M5x0.8

• Fluid: air, inert gas • Operating pressure: 0.15 to 0.7MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.6 • Port size: main valve Rc(PT) 1/8, pilot valve (EXH) M5x0.8

• Fluid: air, inert gas • Operating pressure: 0.15 to 0.7MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.6 • Thread: NPT • Port size: main valve 1/8, pilot valve (EXH) M5x0.8

• Fluid: air, inert gas • Operating pressure: 0.15 to 1.0MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.55 • Thread: G(PF) • Port size: main valve 1/8, pilot valve (EXH) M5x0.8

• Fluid: air, inert gas • Operating pressure: 0.15 to 1.0MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.55 • Port size: main valve Rc(PT) 1/8, pilot valve (EXH) M5x0.8

• Fluid: air, inert gas • Operating pressure: 0.15 to 1.0MPa • Ambient and fluid temp: -5° to 60°C (no freezing) • Effective area (Cv): 0.55 • Thread: NPT • Port size: main valve 1/8, pilot valve (EXH) M5x0.8

• Fluid: air • Operating pressure: 5 to 0.8MPa • Effective area (Cv): 1mm 2 (0.055) • Style of valve: N.C. poppet • Number of ports: 2 or 3 • Piping: side or bottom

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 6mm 2 (0.33) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): 1/8 (6A) • European threads G(PF)

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 6mm 2 (0.33) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): 1/8 (6A) • North American threads (NPT)

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 6mm 2 (0.33) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): Rc(PT) 1/8 (6A)

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 7mm 2 (0.38) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): 1/8 (6A) • European threads-G(PF)

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 7mm 2 (0.38) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): Rc(PT) 1/8 (6A)

• Fluid: air • Operating pressure: -100kPa to 1.0MPa • Effective area (Cv): 7mm 2 (0.38) • Ambient and fluid temperature: -5° to 60°C (no freezing) • Port size (nominal size): 1/8 (6A) • North American threads-NPT
