PROXIMITY SENSORS FESTO - GERMANY

Simple, economical, and precise for measuring, monitoring, and • With analog output • Flush installation • Metric thread

The cylindrical models are supplemented by square designs in various sizes. Thanks to the shape, the sensor can be mounted directly for extreme space efficiency. • Block design • Flush installation • LED switching status indication

The perfect combination of new features—for the most reliable and easy-to-use unit ever. • Reduction factor 1 for all metals • Welding field resistant • Design with housing resistant to welding spatter • Flush, partially flush, or non-flush mounting • LED switching status indication

The perfect solution for detecting metal objects: the inductive proximity sensor SIEN/SIED…-PA. Approved for the food industry and industrial packaging, and also for use in the chemical industry. With standard switching distance • For DC and AC voltage • Metric thread • Flush or non-flush mounting • LED switching status indication • Design with metal or polyamide housing

The inductive proximity sensor SIES-8M for electric actuators is ideal for signaling intermediate and end positions. The only inductive sensor for 8 mm slots, it features a patented status display using two LEDs. Its clamping technology allows it to be positioned quickly and secured easily. • Suitable for position sensing for electric axes and grippers with T-slot Flush installation • Switching status indication with 2 LEDs for better visibility regardless of the direction from which it is appro

The perfect solution for detecting metal objects: the inductive proximity sensor SIEN/SIED…-PA. Approved for the food industry and industrial packaging, and also for use in the chemical industry. • With standard switching distance • For DC voltage • Round design • Metric thread • Flush or non-flush mounting • LED switching status indication • Design with metal or polyamide housin

Robust due to the fully enclosed stainless steel housing, including the active surface. Unlike conventional inductive sensors, the SIEH offers strong resistance to all gases and media. • With increased switching distance • Flush installation • Metric thread • LED switching status indication • Design with stainless steel housing

For contactless pneumatic signal generation at the end of cylinder strokes • Function: 3/2-way valve, normally closed • Can be screwed directly into the supply port of the cylinder using a hollow bo

• Measuring principle: magneto-resistive • Welding field immune design • LED switching status indication

Công tắc xi lanh cảm ứng từ tính gắn trong thiết kế khối. • Nguyên lý đo: điện trở từ • Chỉ báo trạng thái chuyển đổi LED • Chiều dài cáp 2,5 m

Suitable for foodstuffs and easy to clean: magnet-inductive cylinder switch in block design and with clamping claw. • Measuring principle: magneto-inductive • For Clean Design ISO cylinder DSBF with mounting rail for sensors • LED switching status indication

• Measuring principle: magnetic • Pneumatic proximity sensor • Function: 3/2-way valve, normally closed

Attachable magnetic Reed cylinder switch in block design. • Measuring principle: magnetic reed • SMEO-1-S6: heat-resistant design • With or without LED switching status indication • Cable length 2.5, 5 m

Attachable magnetic Reed cylinder switch in block design. • Measuring principle: magneto-inductive • For mounting kit • With or without LED switching status indication

• Measuring principle: magneto-resistive • LED switching status indication

Attachable magneto-inductive cylinder switch. • Measuring principle: magneto-inductive • U-shaped housing • LED switching status indication • Cable length 2.5 m

Attachable magnetic Reed cylinder switch. • Measuring principle: magnetic reed • U-shaped housing • LED switching status indication • Cable length 2.5, 5 m

• Measuring principle: magnetic reed • Corrosion-resistant design • LED switching status indication

Magnetoresistive cylinder switch for round slot, can be pushed in lengthways. • Measuring principle: magneto-resistive • Clamped in C-slot, can be inserted into the slot from above or lengthwise • LED switching status indication • Cable length 0.3, 2.5 m

Magnetic Reed cylinder switch for round slot, can be pushed in lengthways. • Measuring principle: magnetic reed • Clamped in C-slot, can be inserted into the slot from above or lengthwise • LED switching status indication • Cable length 0.3, 2.5 m

Magnetoresistive cylinder switch for round slot, can be inserted from the top. • Measuring principle: magneto-resistive • Clamped in C-slot, can be inserted into the slot from above or lengthwise • LED switching status indication • Cable length 0.3, 2.5 m

Magnetic Reed cylinder switch for round slot, can be inserted from the top. • Measuring principle: magnetic reed • Clamped in C-slot, can be inserted into the slot from above or lengthwise • LED switching status indication • Cable length 0.3, 2.5 m

Welding-proof and attachable: magnetoresistive cylinder switch with M8 plug outlet. • Measuring principle: magneto-inductive • Welding field immune design • Sturdy sensor in block design • Plug integrated in housing • LED switching status indication

Attachable magnetoresistive cylinder switch with M8 plug outlet. • Measuring principle: magneto-resistive • Sturdy sensor in block design • Plug integrated in housing • LED switching status indication

For pneumatic grippers of optimized magnetoresistive cylinder switches for T-slot, can be pushed in lengthways. • Measuring principle: magneto-resistive • SMT-8-F: in accordance with the ATEX directive for explosive atmospheres • SMT-8G: design ideal for gripper sensing • SMT-8-SL: sturdy thanks to long guides and plug directly at the sensor • Variants suitable for use with energy chains and robots • Can be inserted into the slot lengthwise or from above • LED switching status indication

Item No: 178563

Attachable magnetic Reed cylinder switch for T-slot. • Measuring principle: magnetic reed • Sturdy sensor in block design • Plug integrated in housing • LED switching status indication • Cable length 2.5 m

Magnetic Reed cylinder switch for T-slot, can be pushed in lengthways. • Measuring principle: magnetic reed • Variants suitable for use with energy chains and robots • Screw-clamped or clamped in slot, can be inserted into the slot from above or lengthwise • LED switching status indication • Cable length 0.3, 2.5, 5, 7.5, 0.2 ... 10 m

Magneto-resistive proximity sensor for T-slot, for installation from above. Compliant with EU explosion protection directive (ATEX) and fitted with NAMUR output. • Measuring principle: magneto-resistive • Oil-resistant, welding field-resistant, resistant to welding spatter • Can be inserted into the slot from above, secured with screw • LED switching status indication • Cable length 0.3 ... 5 m • SDBT-EX6: To EU Explosion Protection Directive (ATEX)

Corrosion and acid-resistant, ATEX-capable magnetoresistive cylinder switch for T-slot can be pushed in lengthways. • Measuring principle: magneto-resistive • Corrosion-resistant design • Food-safe (see www.festo.com/sp/crsmt-8 -> "Certificates" tab), resistant to acids, lye and cooling lubricants • Can be inserted into the slot lengthwise, flush with the cylinder profile • LED switching status indication • Cable length 0.3 m, 5 m, 10 m

Magnetoresistive cylinder switch for T-slot, can be inserted from the top. • Measuring principle: magneto-resistive • Short design • Variant EX2 for use in potentially explosive areas • Can be inserted into the slot from above, flush with the cylinder profile • LED switching status indication • LED operating reserve indication • Cable length 0.1 ... 30 m

Proximity sensor SME-8M Magnetic Reed cylinder switch for T-slot, can be inserted from the top. • Measuring principle: magnetic reed • Variants suitable for use with energy chains and robots • Screw-clamped or clamped in slot, can be inserted into the slot from • above or lengthwise • LED switching status indication • Cable length 0.3, 2.5, 5, 7.5, 0.2 ... 10 m
